Specification
Viewing Head : 30 degree inclined Binocular head, with locking mechanism
for eyepieces, right diopter adjustment:±; interpupillary distance range:50-75mm.
Eyepiece : Wide field plan eyepiece PL10X/18mm, with reticle, diopter adjustable.
Objective : Plan achromatic objectives 4X/10X/20X/40X/100X (Oil).
Stage : 150mm X 140mm double layer composite mechanical moving stage, double slice clamps, moving range : 76mm
x 50mm; accuracy:0.1mm (triangular guide rail).
Nosepiece : Quadruple nosepiece
Focusing Mechanism : Low position co-axial focusing mechanism , coarse range : 25mm, fine precision: 0.002mm
with tension adjustment and upper limit.
Single – hand LED Fluorescent reflection illumination system : B4 TB-LED fluorescent module for TB,
with intensity adjust knob, BF/FL switching knob. central wavelength455mm.
Illumi1nation System : N.A.1.25 compound eye illumination condenser group (with plug-in phase contrast and dark field
accessories interface), condenser preset center, optional lifting function, adaptive 100V-240V switching power supply, single
high brightness 3W LED (cold/warm color optional, cold color temperature 4750k-5500k, warm color temperature 2850k
3250k) (preset center), light intensity can be continuously adjusted.
Camera Adaptor : 0.5x C-mount adaptor, focusing adjustable.
