(±5). Inter-pupillary distance from 48mm to 75mm. Eyepiece (Anti fungus coated)
Wide Field 10X (paired) F.O.V 20mm. Objectives (Anti fungus coated)
E-Plan Achromatic 4X E-Plan Achromatic 10X
E-Plan Achromatic 40X(S.L.)
E-Plan Achromatic 100X Oil(S.L.) Mechanical Body
Co-axial focusing system. PRE-FOCUSING LEVER & TENSION ADJUSTMENT RING.
The slow motion has 1Div=0.002mm. Quadruple nosepiece revolves on ball bearing.
Double plate mechanical stage size 140mm X 132mm having low positioned co-axial controls. Cross movement 76mm X 50mm.
Sub Stage Condenser
Abbe condenser N.A.1.25 swing out filter holder, iris diaphragm. Illumination System
The built-in-base illumination system with Ultra high brightness single 3W LED cold light source. Brightness control knob.
