JBI-MZ1

JBI-MZ1 Series Monocular Stereo Zoom Video Microscope adopt the Parallel Optical System. It offers sharp clear images, designed for use with a CCD camera. It is widely used in electronic industry, educational demonstration and agricultural research for micro-object observation, inspection, and measurement. 63-180lp/mm resolution meeting the requirements of conventional imaging machine vision.

Eyepiece

Standard



Auxiliary Lens 0.5X



Auxiliary Lens 2.0X



W.D. 100mm



W.D. 165mm



W.D. 30mm



Mag.



F.O.V



Mag.



F.O.V



Mag.



F.O.V

0.35X 0.245X 23mm 0.1225X 46mm 0.49X 11.6mm
1.575X 3mm 0.7875X 7mm 3.15X 1.7mm
0.5X 0.35X 17.6mm 0.175X 35mm 0.7X 8.8mm
2.25X 2.7mm 1.125X 5mm 4.5X 1.3mm
1X 0.7X 9mm 0.35X 17.6mm 1.4X 4mm
4.5X 1.6mm 2.25X 3mm 9X 0.71mm
Magnification 0.35X-2.25X(standard)
Eyepiece 0.5X(standard)
Optional Eyepiece

0.35X, 0.5X, 1X

Objective 0.7X-4.5X stereo zoom; Zoom Ratio:6.4:1
Aux Lens 0.5X, 1.0X, 2.0X
Focusing Mount XLB45-A1 focusing mount with vertical working distance 62mm; ID:50mm for lens


Stand

B3 pole stand


Illumination

Fluorescent lamp, LED ring light
Accessories Can be connected to the cameras and displays
