| Eyepiece | Objective 1X | Objective 2X | Objective 3X | Objective 4X | ||||
|---|---|---|---|---|---|---|---|---|
| Working Distance 100mm | ||||||||
| Mag. | F.O.V | Mag. | F.O.V | Mag. | F.O.V | Mag. | F.O.V | |
| 10X/20mm | 10X | 20.0mm | 20X | 10.0mm | 30X | 7.5mm | 40X | 5.0mm |
| 15X/15mm | 12X | 15.0mm | 30X | 7.5mm | 45X | 5.0mm | 60X | 3.3mm |
| 20X/10mm | 20X | 10.0mm | 40X | 5.0mm | 60X | 3.3mm | 80X | 2.5mm |
| Magnification | 20X-40X, 10X-80X with optional eyepieces and objectives | |||||||
| Eyepiece | WF10X/20mm high-eyepoint, wide-field; Convenient for observers wearing glasses | |||||||
| Optional
Eyepiece |
WF10X/20mm, WF15X/15mm, WF20X/10mm | |||||||
| Main Body | Binocular head, 45° inclined, 360° rotatable, can be locked in any position desired | |||||||
| Interpupillary Distance adjustment:54-76mm; Diopter adjustment:±5 diopters | ||||||||
| Objective | 2X/4X, 3X, | |||||||
| Focusing Mount | Focusing track mount with vertical working distance 50mm | |||||||
| Stand | 2L track stand, for more options | |||||||
| Illumination | Transmitted and reflected LED illumination with independent switches and adjustable intensity | |||||||
JBI-602N
JBI-602 N Series Stereo Microscope has two magnification levels(10x/20x, 10x/30x, or 20x/40x). It is easy to operate and it is an ideal microscope for student learning and classroom teaching. It is also a perfect device for viewing jewel, PCB, insects and so on.
